Wall and floor tiles used for indoor and external decorating are termed whitewares. The process of tile manufacturing stretches back to ancient ages and peoples such as the Egyptians, Assyrians, and Babylonians. The Step Pyramid for Pharaoh Djoser, for example, was erected in ancient Egypt at approximately 2600 B.C. and included multi-coloured glazed tiling. Ceramic tile was afterwards created in almost every major European country and in the United States. Tile production had reached an industrial scale by the early twentieth century. Around 1910, the tunnel kiln was invented, which boosted the mechanisation of ceramic tiles manufacturing. Tile production is now highly mechanised.

Regatta-Tiles-Product-Floor-Header-Image

There are several classifications set the American National Standards in regard to tiles. The tiles can be either of natural clay or ceramic mosaic tile. Paver tile is 39 cm2 (6 in.2) or larger glazed or unglazed porcelain or natural clay tile. Porcelain tile is a type of ceramic mosaic tile or paver tile that is made by dry pressing. Quarry tile is glazed or unglazed tile that is the same size as paver tile but is formed differently.

Europe, Latin America, and the Far East are the main tile manufacturers, with Italy leading the way with 16.6 million ft.2/day in 1989. Following Italy (with 24.6 percent of the global market), Spain (12.6 percent), Brazil and Germany (both with 11.2 percent), and the United States round out the top five (4.5 percent). According to one estimate, the total market for floor and wall tile in 1990 was $2.4 billion.

Raw Materials

When it comes to manufacturing ceramic tiles, the required raw materials are taken from clay minerals extracted from the earth’s crust, natural minerals like feldspar that are employed to bring down the firing temperature, and chemical additives needed for the shaping process. These raw minerals are sometimes enhanced or beneficiated near the stone quarry before sending it to the ceramic plant.

Pulverized raw materials must be categorised according to particle size. Large lumps of material are reduced using primary crushers. A jaw crusher or a gyratory crusher is utilised, both of which use a horizontal squeezing motion between steel plates or a rotating motion between steel cones.

The next-level crushing breaks down larger lumps into smaller pieces. Hammer mills or Muller mills are frequently utilised. A Muller mill crushes the material using steel wheels in a shallow spinning pan, whereas a hammer mill crushes the material with fast moving steel hammers. Crushers of the roller or cone kind can also be employed.

A third particle size reduction stage can be required. Mills that tumble are used in conjunction with a grinding medium. The ball mill, which comprises massive spinning cylinders partially filled with spherical grinding media, is one of the most frequent forms of such mills.

Screens are used to separate particles of varying sizes. They work in a slanted posture and are mechanically or electromechanically vibrated to increase material flow. Mesh number, which is the number of openings per lineal inch of screen surface, is used to classify screens. The smaller the aperture size, the greater the mesh number.

A glaze is a glass substance that is meant to melt onto the surface of the tile during burning and then stick to the surface of the tile during cooling. Glazes are used to offer moisture resistance as well as decoration since they may be tinted or generate unique textures.

The Manufacturing

After the raw ingredients are processed, a series of procedures are taken to produce ceramic tiles. Batching, mixing and grinding, spray-drying, shaping, drying, glazing, and firing are among the stages involved. Many of these stages are now carried out utilising automated machinery.

Batching

The amount and kind of raw ingredients affect the body composition of various ceramic products, including tile. The raw materials also influence the colour of the tile body, which can be either red or white depending on the amount of iron-containing raw materials utilised. As a result, it is critical to combine the correct proportions to create the required qualities. Batch calculations are consequently necessary, which must take both the physical qualities and chemical compositions of the raw materials into account. After determining the right weight for each raw ingredient, the raw materials must be blended together.

Mixing and Grinding

After the components have been weighed, they are combined in a shell mixer, ribbon mixer, or intense mixer. A shell mixer is made up of two cylinders connected by a V that spins to tumble and mix the material. A ribbon mixer employs helical vanes, whereas an intense mixer employs quickly rotating ploughs. This step grinds the components even further, resulting in finer particle size and an improved forming process.

Water is sometimes required to facilitate the mixing of a multi-ingredient batch as well as to obtain fine grinding. This is known as wet milling, and it is commonly done with a ball mill. A slurry or slide is the ensuing water-filled mixture.

Forming

The majority of tile is made through dry pressing. The free flowing powder—containing organic binder or a low percentage of moisture—flows from a hopper into the forming die in this procedure. Steel plungers compress the material in a steel chamber, which is subsequently expelled by the bottom plunger. With working pressures of up to 2,500 tonnes, automated presses are employed.

Several alternative procedures are utilised when the tile body is wetter and more moldable. Extrusion with punching is used to make irregularly shaped tile and thinner ceramic tiles more quickly and cost-effectively. This entails compacting a plastic mass in a high-pressure cylinder and pushing the material to flow out in short slugs.

Drying

After forming, ceramic tile must normally be dried (at high relative humidity), especially if a wet process is utilised. Drying removes water at a slow enough pace to prevent shrinkage cracks, which might take many days. Continuous or tunnel driers that are heated with gas or oil, infrared lamps, or microwave radiation are employed. Infrared drying is ideal for thin tile, whilst microwave drying is ideal for thicker tile. Another approach, impulse drying, employs hot air pulses moving transversely rather than constantly in the material flow direction.

Glazing

The glaze is prepared in the same way as the tile body. Following the calculation of a batch formulation, the raw components are weighed, combined, and dry or wet milled. The milled glazes are then applied using one of many processes. The glaze is fed through a revolving disc that flings or tosses the glaze onto the tile in centrifugal glazing or discing. A stream of glaze falls onto the tile as it travels beneath a conveyor in the bell/waterfall process. The glaze is sometimes simply sprayed on. Screen printing on, beneath, or between wet glazed tile is used for various glaze applications. Glaze is driven through a screen using a rubber squeegee or other instrument in this procedure.

Firing

After glazing, the ceramic tiles must be intensively heated to reinforce it and achieve the necessary porosity. There are two kinds of ovens, or To prevent cracking and shrinking, the file is dried slowly (over many days) and at high humidity once it has been formed. The glaze is next added, and the tile is burned in a furnace or kiln. Although some tile requires two firings, wet-milled tile is simply burned once, at temperatures of 2,000 degrees Fahrenheit or more. The tile is packaged and sent once it has been fired.

Before glazing, the tile goes through a low-temperature fire called bisque firing. This phase eliminates the volatiles and most or all of the shrinkage from the material. The body and glaze are then burned jointly in a technique known as glost firing. Both fire procedures take place in a tunnel or continuous kiln, which comprises of a chamber through which the ware is gently carried on a conveyor on refractory batts—high-temperature-resistant shelves—or in saggers. Tunnel kiln firing can take two to three days, with temperatures of 2,372 degrees Fahrenheit (1,300 degrees Celsius).
